CAMWorks 2022 SP3 Multilang for SolidWorks 2021-2022 [2022, MULTILANG +RUS]
Size: 2.54 GB Type: APPS Year: 2022 Version: 2022 SP3 build 2022/0708
Year/Date of Issue: 2022
Version: 2022 SP3 build 2022/0708 (08 Jul-2022)
Developer: Geometric Technologies, Inc.
Developer site: camworks
Bit depth: 64bit
Interface language: Multilingual (Russian is present)
Tabletka: Present (TeAM SolidSQUAD-SSQ)
System Requirements: SolidWorks 2021-2022 preinstalled
MS Access 2010-2019 32/64bit
Graphics 1024x768 resolution with minimum 32768 colors
Disk Space 10GB free
Memory 1GB+ RAM (2GB recommended)
Description: CAM(Computer Aided Manufacturing)Works is a module for creating control programs for CNC machines.
Programming of milling, turning, turn-milling and wire erosion processing by means of the CAMWorks module.
* Module CAMWorks allows you to create programs for milling, turning, turning-milling and wire erosion. The following types of machines are supported: Milling with simultaneous control of two ? five axes;
* Turning one- and two-spindle, with one or two calipers, with program-controlled auxiliary mechanisms (tailstocks, lunettes, parts catchers ...);
* Turning and milling one- and two-spindle, with one or two calipers, with program-controlled auxiliary mechanisms, with simultaneous control of two to five axes;
* Erosion two- and four-axis.
Processing is carried out directly in the SolidWorks environment and directly on the SolidWorks model. The results of the programmer's work are saved in the same SolidWorks part or assembly model. This ensures that the model and toolpaths are fully associative, resulting in automatic updates of all toolpaths when changes are made to the model. When adding any technological data to the SolidWorks model, such as roughness designations, bases, tolerances of the shape and location of surfaces, dimensional tolerances, the technologist-programmer always has direct access to them, which makes it easier to select the scheme for basing the part on the machine and select the necessary for ensuring the specified quality of the tool part and cutting conditions. The part can be easily adapted to the needs of processing by, for example, eliminating geometry elements that are unnecessary from the point of view of processing or by recalculating the model's performance dimensions to the middle of the tolerance field. In the SolidWorks assembly mode, you can perform joint processing of several parts, program the processing of a series of parts, or simply completely simulate the entire real situation on the machine table - all tooling, a workpiece of any complexity, and so on - to fully take into account the realities of processing at the earliest stages. creating a programpic
n principle, it will work without these requirements, but the full system load will increase from seconds to several minutes minutes.
