Drafter 3.91 | 3.2 Mb
Drafter is intended for designers of all kinds of pipe networks, pipelines, and so on. It offers help from entering the data of nodes, automatically assigning some values, until a pipe network drawing is generated. The drawing can be modified in most CAD applications or printed directly from Drafter. Due to its many built-in functions and ready-made objects for wastewater treatment plants, the program is particularly well suited for sewage networks. It is equally well used by users to create drawings of: water supply, gas, drainage and even to create road cross-sections.
Drafter automatically creates profiles of pipe networks. It was developed for creating sewage network profiles, however it can be successfully used for other network types.
Drafter:
automatically sets the characteristic values,
generates drawings in vector format dxf (can be further processed in most CAD software),
allows direct printing the generated profiles without any additional software,
it has built-in, ready-to-use objects: (e.g.: septic tanks, manholes, dampers, pipes),
generates pipe networks statistics,
greatly speeds up the creation and modification of drawings.
is flexible - has many configuration options.
Operating System:Windows 7, 8/8.1, 10, 11
Home Page-http://drafter.wisart.eu/index.php
