Siemens Simatic WinCC 7.5 Update 4 | 2.3 Gb
Siemens AG has released an update 4 to Simatic WinCC 7.5. This the scalable and open SCADA system for maximum plant transparency and productivity.
The behavior of the WinCC components has been improved compared to WinCC 7.5, including previous patches in the following areas:
WinCC Basic
WinCC Projects
- WinCC ServiceMode: Administrator rights are not required to print via global scripts
- Text Distributor: Import of export files that were edited with MS Excel.
- Migrated projects: Stability of the "Menus and toolbars" editor
Graphics Designer
- Performance duringediting of process pictures that contain many objects of the type "Connector"
- Status display (extended): When a subfolder of "GraCS" contains a graphics file, the preview iscorrectly displayed in the extended status display.
- Animation: An expression that contains addition and multiplication is interpreted just as it is in Global Script and in the dynamic dialog.
- Faceplate instances: Changes of instance-specific properties are retained when the processpicture is closed.
- Linking of a structure tag to a faceplate instance to dynamize instance-specific tags with an animation
- The TABsequence onlyhas aneffectonthe selected object types.
Tag Management
- AS tags: Expandingall nested tags for a complete view
- AS tags: Updating tags that were imported with "Loadfrom file"
- During the importofAS structures, arrays of the type "Struct" are applied correctly.
- Arrays ofthetypeUDT: The tag names are imported correctlyduring "Load from file".
- The import of tags using "Load from file" is not canceled when importing a tag with the data type "TCON_IP_v4".
Graphics Runtime
- Bar object: Display of the scale and the process value with dynamic change of the limits
- ActiveX control "Microsoft Forms 2.0 CommandButton": Same behavior for touch operation and operation with the mouse
OPC Server
- WinCC OPC UA s erver: Access to archive tags when the WinCC GUI language "French" isselected
WinCC Channels
OPC UA WinCC Channel
- Display of array elements in the WinCC tag management
SIMATIC S7-1200 S7-1500
- ChannelCommunication with the PLC
WinCC/WebNavigator
Web Client
- Web Cross Connectivity: Filtering messages
- Basic Process Control: Picture navigation when the pictures are stored in subfolders of "GraCS"
WinCCViewerRT
- Independent picture windows can be minimized.
- An error message due to insufficient operating rights only occurs when the user does not have the necessary authorizations.
WinCC/WebUX
Runtime
- Stability when refreshing the browser, e. g. using
- WinCC AlarmControl: The "Single acknowledgment" button is no longer active when selecting already acknowledged messages.
WinCC/DataMonitor
Siemens Security Advisory for WinCC
- You can find information on closed security vulnerabilities in the security advisories at:
Код:
http://www.siemens.com/cert/advisories- Stability of Excel Workbook Wizard when SIMATIC NET PC 14 is installed
With the SCADA system SIMATIC WinCC 7.5 Siemens offers an innovative, scalable process-visualization system with numerous high-performance functions for monitoring automated processes. Whether in a single-user system or a distributed multi-user system with redundant servers, the system offers complete functionality for all industries and features optimum openness.
Due to the permanently increasing level of automation and the related complexity of the plants the cost - and time - pressure is increasing because of the international competition. One response to this pressure has to be efficient engineering on the SCADA layer.
SIMATIC WinCC supports short Time-to-Market when building new plants and achieves a minimum of downtime when doing plant modifications because of its efficient engineering tools.
Siemens AG (Berlin and Munich) is a global technology powerhouse that has stood for engineering excellence, innovation, quality, reliability and internationality for 170 years. The company is active around the globe, focusing on the areas of electrification, automation and digitalization. One of the world's largest producers of energy-efficient, resource-saving technologies, Siemens is a leading supplier of efficient power generation and power transmission solutions and a pioneer in infrastructure solutions as well as automation, drive and software solutions for industry. The company is also a leading provider of medical imaging equipment - such as computed tomography and magnetic resonance imaging systems - and a leader in laboratory diagnostics as well as clinical IT.
Product: Siemens SIMATIC WinCC
Version: 7.5 Update 4
Supported Architectures: 32bit / 64bit
Website Home Page :
Код:
www.plm.automation.siemens.comSystem Requirements: PC *
Supported Operating Systems: *
Software Prerequisites: *
Size: 2.3 Gb
Hardware requirements
- No change compared to WinCC 7.5.
Software requirements
- WinCC V7.5 or at least an option from WinCC V7.
The following Microsoft operating systems are supported with WinCC 7.5:
For WinCC server / single-user / clients / Web clients
- Windows 10 (64-bit) Professional, Enterprise
- Windows 10 (64-bit) Enterprise LTSB (Long-Term Servicing Branch)
- Windows Server 2012 R2 (64-bit) Standard, Datacenter
- Windows Server 2016 (64-bit) Standard, Datacenter
With Windows 10, a maximum of three client connections is possible in multi-user systems.
For WinCC/WebNavigator clients and WinCC/DataMonitor clients, the following are also approved:
- Windows 7 SP1 Professional, Enterprise, Ultimate 32-bit / 64-bit
- Windows 8.1 Professional, Enterprise 32-bit / 64-bit
