x64 | Languages:Multilanguage | File Size: 732 MB
Description:
FloEFD for CATIA V5 applications for modeling the flow and heat transfer in liquids and gases in a DS CATIA V5 environment. FloEFD is fully integrated into the DS CATIA V5 environment and uses solvers based on computational fluid dynamics (CFD) technology. Main advantages. Working directly with the model in the DS CATIA V5 environment. There is no need to convert the geometry to another format, often leading to loss of quality. The task of calculating hydrodynamics and heat transfer at any moment of time it is completely synchronized with the model Minimization of efforts, and as a result, errors in the synchronization process of the stated hydro-gas-dynamic problem and model
Automatic detection of changes in the model. There is no need for "manual" construction of the geometry describing the area occupied by the liquid / gas. Automatic determination of the area occupied by the liquid / gas. It uses the same graphical controls as other DS CATIA V5 modules. Very easy to learn. Easy to use. Uses the DS CATIA V5 model tree. Intuitive and fully interactive Use when creating a project / processing the results of model elements selected in the graphics window / model tree Visualization of calculation results in the form of static and animated images directly in the graphics window
Support for exporting results to MS Excel, Word. Ability to play and record animations.Support for multi-configuration of the model.For effective multi-parameter research, implemented are the ability to clone projects, automatically start a series of calculations. It is automated to reduce the number of cases when it is necessary to involve specialists in the field of gas-gas dynamics and heat transfer to analyze the formulation and calculation results Reliable and fully automatic computational grid generator A unique model of turbulence and boundary layer is used Automatic control of solution convergence. Reliable and accurate numerical methods and physical models A wide range of physical models Exact solution The ability to calculate very complex structures and physical phenomena.
Computational Fluid Dynamics (CFD) also allows you to analyze a wide range of complex problems, including:
-Analysis of hydro-aerodynamics and heat transfer of two- and three-dimensional models
-Analysis of external and internal flow patterns
-Analysis of steady and unsteady flow
-Flow of incompressible fluid and compressible gas including including combustible mixture at subsonic,
transonic, supersonic and hypersonic modes itecheniya
-Condensation of steam
-calculation of the relative humidity in the gas streams
-Non-Newtonian flow and Liquids (only laminar flow regime)
-Flow in a compressible fluid (fluid density depends on pressure)
-Flows in real gases
-Analysis of Laminar, turbulent and transient flows
-Analysis of vortex flows and fans
-Analysis of flows with solid inclusions
-Analysis of heat transfer inside and between liquids and solids
-Analysis of heat transfer inside solids in lack of washing the flux
-calculation of the thermal contact resistance
-calculation of the electric contact resistance
-Thermoelectric coolers
-heat radiation
-Joule heating
-flows with gravity effects (also known as the buoyancy effect)
-Porous media
-Heat pipes
-Heat transfer in printed circuit boards
-Heat transfer in perforated plates
-Flow of aerosol flows
-Consideration of body roughness during flow
-Consideration of tangential wall motion (mixing and rotation)
-Flow in rotating devices
-Cavitation in fluid flows
-Combustion in gas mixtures
Details:
Siemens Simcenter FloEFD 2019.3.0 v4745 for CATIA V5 Win64
Release Year / Date:2019
Version:2019.3.0 v4745
Developer:Siemens PLM / Mentor Graphics
Architecture:64bit
Interface language:English,German,French,Chinese,Japanese,Russian
Tabletka
resent (TeAM SolidSQUAD-SSQ) System Requirements:
-OS:Microsoft Windows 7 Professional, Ultimate or Enterprise 64-bit edition, Microsoft Windows 10 Pro or Enterprise 64-bit (tested with v1809) For solver: Microsoft -Windows 2012 Server x64, Windows 2012 Server R2 x64,Windows Server 2016 with HPC Pack 2016
-Memory:4 GB RAM minimum, more recommended
-Space:1 GB of free hard disk space, more required for simulation models
-Microsoft Windows Media Player 7.0 or higher
-Mouse or other pointing device
Softwares:
-Microsoft Office 2013; Microsoft Office 2010 Microsoft Office 2007
-CATIA V5R19 (recommended SP9)
-CATIA V5R20 (recommended SP7)
-CATIA V5-6 2012 (R22) (recommended SP6)
-CATIA V5-6 2013 (R23) (recommended SP6)
-CATIA V5-6 2014 (R24) (recommended SP7 )
-CATIA V5-6 2015 (R25) (recommended SP6)
-CATIA V5-6 2016 (R26) (recommended SP6)
-CATIA V5-6 2017 (R27) (recommended SP4)
-CATIA V5-6 2018 (R28) (recommended SP0)
-CATIA V5-6 2019 (R29) (recommended SP2)Whats New:
read:FLOEFD_Release_Notes_2019.3.pdf
