MSC Nastran 2020 SP1 + Documentation | 3.9 Gb
MSC Software recently released version 2020 SP1 of its flagship finite element analysis (FEA) solver, Nastran. This release corrects four defects evident in version 2020 that concern the import of Nastran Embedded Fatigue and acoustic pressure results into Patran; corrects a licensing defect concerning the TABLRPC entry; and shell elements SFRP failure indicator output in the Digimat-to-SOL 400 MATDIGI interface.
[b
The highlights of this release include:[/b]
- A defect causing Patran 2019 Feature Pack 1 to fail to attach to a Nastran version 2020 Nastran Embedded Fatigue OP2 file is fixed. The OEFTG.DDL HIST items were moved to a separate datablock but actually remained in place causing the Nastran toolkit to fail.
- A defect (related to the above) causing a fatal message on the same fatigue run is fixed.
- Incomplete HDF5 support of Nastran Embedded Fatigue output.
- Incorrect acoustic pressure results read into Patran
- A defect causing a licensing error when Patran accesses the Nastran toolkit with an input deck containing a TABLRPC entry is fixed.
MSC Nastran is a multidisciplinary structural analysis application used by engineers to perform static, dynamic, and thermal analysis across the linear and nonlinear domains, complemented with automated structural optimization and embedded fatigue analysis technologies, all enabled by high performance computing.
MSC Nastran is based on sophisticated numerical methods, the most prominent being the Finite Element Method. Nonlinear FE problems may be solved with built-in implicit numerical techniques. A number of optimization algorithms are available, including MSCADS and IPOPT.
MSC Nastran is a memory dependent software and users have to make sure that sufficient memory is allotted to MSC Nastran resources (Solver OpenCore, Buffer Pool, Scratch memory etc) to make sure the job runs faster. The command line settings are very much dependent on the model and the solution type. MSC Nastran jobs can be solved using Shared Memory Parallelization (SMP) and Distributed Memory Parallelization (DMP) settings.
MSC Nastran 2020 Release Highlights
MSC Software is one of the ten original software companies and a global leader in helping product manufacturers to advance their engineering methods with simulation software and services. As a trusted partner, MSC Software helps companies improve quality, save time, and reduce costs associated with design and test of manufactured products. MSC Software is based in Newport Beach, California and employs 1,200 professionals in 22 countries. Having established its subsidiary in Tokyo, Japan in February 1982, it now has its offices in Osaka and Nagoya.
Product: MSC Nastran
Version: 2020 SP1 with Documentation
Supported Architectures: x64
Website Home Page :
Код:
http://www.mscsoftware.comSystem Requirements: PC *
Supported Operating Systems: *
Size: 3.9 Gb
Installation Notes
You must have one of the following systems to install and run MSC Nastran:
- Windows 7-64 or Windows 10-64, with at least 4 Gigabyte RAM, and 20 Gigabytes available disk space to install MSC Nastran.
- Microsoft 2010 Redistributables are required. They may be downloaded from:
