Vero WorkXplore 2021.0.2035 | 426.2 mb
Hexagon's Manufacturing Intelligence division is pleased to announce the release of Vero WorkXplore 2021.0.2035, the most powerful, full-featured, high-speed CAD file viewer and analyzer available in today's market.
[b
WorkXplore 2021.0 - What's new[/b]
Assembly View New Visualization for Components
It is now possible to easily highlight parts in an assembly. In fact, the selected component is displayed in a vibrant colour whilst the assembly appears in a transparent style in the background. The purpose of this visualization is to show the position of a certain isolated part in an assembly with the focus on the selected component primarily.
In addition, it is possible to pick any component of the model in the graphic area so to highlight it in the assembly tree structure that can then be easily navigated.
Designer Reading
The direct import of Designer files is now possible.
ACIS Reading of SAB Files
The possibility to read files in binary format has been added to the ACIS interface. Currently supported versions are until 2019.1.0.
Client Viewer Refurbishing
This tool, that enables users to communicate 3D parts and assemblies to sub-contractors, customers or colleagues using a standalone, lightweight application that can be easily transmitted via the Internet, has been reviewed and enhanced.
First, it is now possible, through the export window, to choose between the creation of 32- or 64-bits Client Viewer executables. The latter allows big models/assemblies to be exported correctly.
In addition, it has been added the ability to export WorkNC Toolpaths.
Translators - Supported Formats
The incessant enhancements to consolidate WORKXPLORE and make it even more efficient have been applied to commands and libraries.
This release continues WXP's long tradition of bringing updated format support and continued enhancements and fixes to further improve the robustness and performance of interoperability.
PXP-1002 CATIA V5 Import - Leave Invisible not Respected with this File
PXP-2353 CATIA V5 Import - Wireframe Entities and GD&T not Imported
PXP-2323 CATIA V5 Import - Assembly Takes Much More Time to Load
PXP-1827 CATIA V5 Import - Never Finishes Loading Attached Model
PXP-2978 CATIA V5 Import - Solid is Incorrectly Imported (Missing Surfaces)
PXP-2385 STEP Import - Untrimmed surface when importing with Advanced Import
PXP-2604 Pro-E/CREO Import - Untrimmed Surface when Importing Attached File
PXP-1558 Inventor Import - Empty Model after Import 3D Dialog
PXP-3053 Update Datakit 2020.3
PXP-3046 NX Import - Support for NX 1899
PXP-2366 DWG Import - Unknown Error "nº %d." when Trying to Open File
PXP-3014 Update Datakit 2020.2
PXP-1796 CATIA V5 & V6 Import - GD&T Data not Imported [Datakit #16039 #16041 #16042]
PXP-2141 CATIA V5 Import - Extra Solid is Imported [Datakit #16183]
PXP-2190 STEP Import - Axis System is not Loaded [Datakit #16307]
PXP-2971 Pro-E/CREO Import - Attached Assembly is Partially Loaded
PXP-2934 Solid Edge Import - Support for 2020 2D Drawings [Datakit #17238]
WorkXplore is the ideal tool for directly displaying and evaluating 3D CAD files without the need for the original CAD application. The intuitive, easy-to-use interface enables novice and experienced users alike to explore any type of 2D/3D CAD file.
WORKXPLORE enables users to build virtual unified prototypes or 3D models from files imported from various CAD applications. Users can work on model set up and improvements before committing time and resources to creating a real prototype.
A wide range of CAD interfaces are available: VISI, Catia V5, Catia V4, Unigraphics, Parasolid, Pro/E, SolidWorks, Solid Edge, Cadds, IGES, STEP, Unisurf, STL (binary and ASCII), VRML, DXF, DWG, HPGL.
WORKXPLORE has been created for the efficient import and analysis of files of all sizes and types but it is the speed at which it imports large 3D CAD files which is particularly impressive, often taking less than half the time to open a file compared to the original CAD application.
The software saves the native CAD data in its own lightweight format enabling users to calculate surface areas and volumes, measure thickness, dimensions and angles and much more without requiring the original CAD data. This lightweight format can be easily transmitted to other project members via email.
What's New | WorkXplore 2021.0
Hexagon's Manufacturing Intelligence Division helps industrial manufacturers develop the disruptive technologies of today and the life-changing products of tomorrow. As a leading metrology and manufacturing solution specialist, our expertise in sensing, thinking and acting - the collection, analysis and active use of measurement data - gives our customers the confidence to increase production speed and accelerate productivity while enhancing product quality.
Hexagon acquired Vero Software, a specialist in CAD CAM software, in 2014 and has continued to expand and diversify its offering.
Product: Vero WorkXplore
Version: 2021.0.2035
Supported Architectures: x64
Website Home Page :
Код:
http://www.workxplore.comSystem Requirements: PC *
Size: 426.2 mb
System Requirements for WorkXplore
Processor
Minimum configuration: Core 2 Duo (2 GHz), Athlon_64X2 (2,6 GHz)
Recommended configuration: Intel Xeon 2.66 GHz memory 1066 MHz (or more: 1333 MHz) (multicore or multi-processor)
Operating system
Minimum configuration: Windows 7 Pro, Windows 8 Pro, Windows 10 Pro 64 Bits (*)
Recommended configuration Windows 7 Pro, Windows 8 Pro, Windows 10 Pro 64 Bits (*)
Graphics card
Minimum configuration: 2GB of memory with Open/GL 3.3 compatibility (Intel chipsets are not recommended)
Recommended configuration: 4GB (or more) of memory with Open/GL 3.3 compatibility (Intel chipsets are not recommended)
Hard disk
Minimum configuration: 250 MB (or more) disk space (*)
Recommended configuration: 500 MB (or more) disk space
Screen
Minimum configuration: 17" Monitor - Minimum resolution 1280 x 1024
Recommended configuration: 19" or 24" Monitor - Minimum resolution 1280x1024
RAM
Minimum configuration: 4 GB DDR
Recommended configuration: 8 - 16 GB DDR
Mouse
Minimum configuration: Mouse wheel (or minimum 3 buttons mouse)
Recommended configuration: Mouse wheel (or minimum 3 buttons mouse)
Software installation
Minimum configuration: WEB access (Download)
Recommended configuration: WEB access (Download)
Additional software
Minimum configuration: Installed and configured TCP/IP software (For license server use)
Recommended configuration: Installed and configured TCP/IP software (For license server use)
* Depends on the size of the part (large parts will have highter memory requirements). We recommend to always download the latest graphic card driver from the supplier's Web site. If using two screens, do not use "Nview" function.
