Autodesk Powermill 2020.2.2 Update

akare

Member


Autodesk Powermill 2020.2.2 Update | 257.9 mb
Languages: 中文 Simplified, 中文 Traditional, Čeština, english, Français, Deutsch, Magyar, Italiano,
日本語, 한국어, Polski, Português, Русский, Slovenčina, Español, Türkçe

The Autodesk NC CAM team has launched the new release PowerMill 2020.2.2. The last release of PowerMill represents a significant shift in development in recent years - with a clear focus on usability, reliability, and speed.

Toolpaths
- Fixed an issue where the tool overhang could unexpectedly revert to zero length, leading to gouges.
- Fixed an issue that caused drilling segments to lose their simulated orientation vector and make the toolpath 5 axis when a project was saved and reloaded.
- Fixed an issue that led to the simulated orientation vectors not being set on the last point of toolpaths, sometimes resulting in 3+2 toolpaths becoming 5 axis.
- Fixed an issue that could result in collisions remaining in toolpaths calculated with automatic collision avoidance. PMILL-13119
General
- .pmlprjz project archive files can now be imported by dragging and dropping them onto the PowerMill graphics window.
- Fixed an issue that caused some text to display incorrectly when using PowerMill in a display language other than English.
- Fixed an issue introduced in PowerMill 2020.0.1 security fix that stopped printing from working correctly.
- Fixed an issue where hole feature sets in the Explorer tree would stop being displayed in bold.
Customer error reporting (CER)
- Fixed an issue that caused PowerMill to occasionally close unexpectedly while performing multithreaded calculation of 2D Curve Profile toolpaths. This issue was identified by CER.
- Fixed an issue that could cause PowerMill to close unexpectedly while loading a project. This issue was identified by CER
- Fixed an issue that could cause PowerMill to close unexpectedly when verifying or simulating toolpaths with the Use Simulated Orientations option enabled. This issue was identified by CER.
- Fixed an issue that could cause PowerMill to close unexpectedly while calculating a multi-axis drilling toolpath when a previous toolpath had used the fit arcs point distribution. This issue was identified by CER.
Security
- Fixed a potential vulnerability issue.



PowerMill is Autodesk's CAM solution for high-speed and five-axis machining. It offers a comprehensive range of strategies and powerful editing tools to ensure efficient, safe and accurate machining, especially for companies that are using sophisticated CNC machine tools to produce complex shapes in challenging materials. PowerMill is used in a wide range of industries but is particularly successful in mold, tool and die, complex aerospace and automotive applications.

The release of PowerMill 2020 represents a significant shift in development in recent years - with a clear focus on usability, reliability, and speed.

The previous releases of PowerMill have seen significant improvements in terms of robustness and safety. Technology such as collision avoidance using automatic tool-axis tilting makes it easier for CAM programmers to create safe NC code that can be run on their CNC machines. Autodesk's pursuit of safe, collision-free toolpaths has resulted in the introduction of additional safety checks within the core PowerMill algorithm. These safety checks are a good thing - but they do carry a processing overhead which can have an impact on overall calculation time.

In direct response to feedback from customers and internal users, the Autodesk PowerMill team re-focused its development muscle on outright performance (speed).

Watch this selection of videos to see the latest enhancements to Autodesk PowerMill. The 2020 release offers significant speed improvements to toolpath calculation, simulation, and verification, plus enhanced leads and links, uphill corner finishing and a new model filleting option for Optimized Constant Z and Steep and Shallow Finishing.

Speed Improvements - PowerMill 2020
Multi-Threaded Leads and Links - PowerMill 2020
Uphill Corner Finishing - PowerMill 2020
Model Filleting - PowerMill 2020

Autodesk helps people imagine, design and create a better world. Everyone-from design professionals, engineers and architects to digital artists, students and hobbyists-uses Autodesk software to unlock their creativity and solve important challenges.

Product: Autodesk PowerMill
Version: Ultimate 2020.2.2 Update Only
Supported Architectures: x64
