CADprofi Suite helps in designing architectural and mechanical projects, as well as plumbing and electrical installations.
Examples of using CADprofi Suite:
When designing electrical and HVAC installations, you can first quickly draw building plans using the architectural module.
The rooms defined in the architectural module can be exported to the DIALux program as a ready building outline. Then, lighting fixtures selected in DIALux can be easily imported into the electrical module and afterwards you can easily assign them to appropriate electrical circuits and create specifications. Thanks to this, you can finish a complete project much faster and easier.
In the architectural module you can designate rooms, and then using the Arrange command you can quickly arrange fire detectors, sprinklers and other objects from the electrical and HVAC & Piping modules.
In the mechanical module you can design mounting method for tanks, trays and other objects from the electrical module as well as HVAC & piping systems.
You can design evacuation and fire protection plans, including:
- in the architectural module you can quickly draw building plans and create evacuation, fire protection and safety plans.
- in the electrical module you can design fire detection systems, emergency lighting and other intelligent building and safety systems.
- in the HVAC & Piping module you can design any piping and vent.
installations, including fire extinguishing and smoke venting systems.
In the architectural module you can easily define the technical parameters of the rooms (lighting, ventilation, temperature, heat loss).
When creating a building plan in the architectural module, you can
show the location of radiators (e.g. under windows or on the walls) from the HVAC & Piping module.
In the architectural module, you can easily insert bushings (culverts) for pipes, ventilation ducts and cable trays.
Our current program versions are compatible with:
4M CAD V14 - V16, V19, V21
ActCAD 2020 (64bit)
ARES Standard Edition 2019
ARES Commander Edition 2012 - 2020
AutoCAD 2000 - 2021 (32/64bit)
AutoCAD LT 2000 - 2019 *) (32/64bit)
AutoCAD Architecture 2000 - 2021
AutoCAD Mechanical 2000 - 2021
AutoCAD MEP 2008 - 2021
AviCAD 2014 - 2017, 2019
BricsCAD V4 - V21
CADian 2012 - 2017, 2020
CADMATE 2015 - 2016, 2018
CADopia 8, 19
CMS IntelliCAD 7.2, 8.1, 8.2 x64, 8.3, 8.4, 9.0, 9.1, 9.2 (64bit)
GstarCAD 2010 - 2020
IBSCAD 2018, 2019
IntelliCAD 5, 6, 7.2, 8.1
IntelliPlus 8, 2013 - 2014
progeCAD 2008 - 2021
ZWCAD 2008i - 2012, ZWCAD+**, ZWCAD Classic, ZWCAD 2017 - 2021**
Other programs on request
