Free Download OpenFlows Sewer 2024 Update 2 v24.00.02.21 | 1.4 Gb
The
Hydraulics and Hydrology development teamis pleased to announce the availability of
OpenFlows Sewer 2024 Update 2 (24.00.02.21). is a comprehensive hydraulic analysis application that enables engineers to design and analyze sanitary, stormwater, and combined sewer systems using built-in hydraulic and hydrologic capabilities.
Owner:Bentley Systems Inc.
Product Name:OpenFlows Sewer
Version:2024 Update 2 (24.00.02.21)
Supported Architectures:x64
Website Home Page :
У вас нет разрешения на просмотр ссылки, пожалуйста
Вход или
Регистрация
Languages Supported:english
System Requirements:Windows *
Size:1.4 Gb
Now, they can meet increasing population demands, address aging infrastructure challenges, and decrease risks.
Starting with version 24.00.01.05 look for the new bundled product names:
- OpenFlows Water contains WaterGEMS, WaterCAD, and HAMMER
- OpenFlows Sewer contains SewerGEMS and SewerCAD
- OpenFlows Storm contains StormCAD, PondPack, and CivilStorm
- OpenFlows Hydraulic Toolset contains Flowmaster and Culvertmaster
Overview
A new version of OpenFlows Sewer 2024, which consists of SewerGEMS and SewerCAD, has been released.
Table of Contents
- Coordinate system support in Standalone
- Improvements to 2D engine performance
- Edit Bends tool
- Zoom-dependent visibility for background layers
- Display Inactive Topology option added to Ribbon
- Improved query preview in Query Builder
- Support for AutoCAD 2024 and 2025
- Support for MicroStation 2023, 2024 and CONNECT Edition
- Support for ProjectWise 2023 and 2024
- Supported Operating Systems and Platforms
- Model Compatibility
- Stability enhancements and fixes to reported issues
Coordinate system support in Standalone
Coordinate systems are now supported in the Standalone platform. With this version, coordinate system support currently only influences the ability to align the model with a Bing Map background. This enables users to more easily align the model with the background without having to manually align three points. Future versions will be able to use the established coordinate system with tools such as ModelBuilder, LoadBuilder, Terrain Extractor and Terrain models, when using external data with an established coordinate system. (including the ability to reproject).
When you open the Bing Maps option in the Background Layers manager, you will now see a Coordinate System option in the Map Alignment section
Close
You can click the Select Coordinate System button to open the manager where you can choose the coordinate system. Options for Projected and Geographic coordinate systems are available for selection. When you choose an option, you will see details on the coordinate system displayed.
Close
The Select Coordinate System manager is also available from the Options dialog (Home > Options > Hydraulic Model.
If you select the Manual option for the Map Alignment, you can still enter the 1 or 3 Control Point options to add a Bing Map background.
See this link for more information on this feature: Working with coordinate systems in the OpenFlows standalone platform.
A note on Coordinate Systems and Shapefile Export - starting with this version, shapefiles exported from element flextables will generate a .PRJ file containing the coordinate system, if a coordinate system has been specified in the model.
Improvements to 2D Engine performance
A number of improvements have been made to the 2D solver. This will make the calculation and usage of 2D modeling more efficient.
Edit Bends tool
A tool has been added to make it easier to add or remove bends in a pipe. To access this, right-click on a pipe and select Bends > Edit Bends. This will open a Select toolbar with options to add a bend, remove a bend, or remove all bends. Existing bends on the pipe will also be displayed when the tool is active.
Close
Zoom-dependent visibility for background layers
A new feature to make background layers zoom-dependent has been included for most background layer types. This is related to the Zoom Level that you can find to the lower left of the drawing pane.
If you right-click on an existing background layer, you can select "Set zoom limits." This will open the zoom limit settings in the Properties grid. You can select the zoom out and zoom in limit. If the Zoom Level for the drawing is outside of the range, the background layer will no longer display.
Close
In the example above, the Zoom Out Limit is set to 55% and the Zoom Level is currently 55.5%. At this Zoom Level, the background layer will display. However, if you were to zoom out to a Zoom Level of 50%, the background layer will no longer be visible in the drawing.
Display Inactive Topology option added to Ribbon
The option to enable or disable how inactive topology is displayed has been included directly in the Ribbon interface. To get to this, go to Home > Active Topology or Tools > Active Topology.
Close
Clicking on Display Inactive Topology will toggle this setting. If the checkmark is next to the item, the inactive elements will be displayed.
The default color for inactive elements is gray. If you want to adjust the color, go to File > Options and go to the Layout section of the General tab.
Improved query preview in Query Builder
The Query Builder has an improved Query Preview section, which will display a more meaningful preview of the query you are creating, rather than the name of the item from the SQLite database.
Close
The Query Preview will display a more logical description of the query, while the SQL Query Preview will display the query using the name of the field in the database file.
Support for integration with AutoCAD 2025
The new releases support integration with AutoCAD 2025.
Support for integration with MicroStation 2024
The new releases support integration with MicroStation 2024.
Support for ProjectWise 2023 and 2024
Support for ProjectWise 2023 and 2024 have been included.
Model Compatibility
Older models can be opened in this version of OpenFlows Sewer and OpenFlows Storm.
Models saved in 2024 can still be opened in 2023.
Stability enhancements and fixes to reported issues
As with all new versions, this release includes fixes to various user-reported issues from the previous release, providing an overall more stable experience.
OpenFlows SewerGEMSis the first and only fully-dynamic,multi-platform (GIS, CAD, and Stand-Alone) sanitary and combined sewer modelingsolution. With SewerGEMS, you will analyze all sanitary and combinedsewer system elements in one package and have the option of performing theanalyses with the SWMM algorithm or our own implicit solution of the full SaintVenant equations. Simply put, SewerGEMS offers the most comprehensive solutionavailable for optimizing Best Management Practice (BMP) designs and meetingsanitary sewer overflow (SSO) and combined sewer overflow (CSO) regulations.
OpenFlows SewerCADis the first and only fully-dynamic, multi-platform (GIS, CAD, and Stand-Alone) sanitary and combined sewer modeling solution. With SewerCAD, you will analyze all sanitary and combined sewer system elements in one package and have the option of performing the analyses with the SWMM algorithm or our own implicit solution of the full Saint Venant equations. Simply put, SewerCAD offers the most comprehensive solution available for optimizing Best Management Practice (BMP) designs and meeting sanitary sewer overflow (SSO) and combined sewer overflow (CSO) regulations.
Sewer Fundamentals Training (SewerGEMS/SewerCAD)
Bentley Systems, Inc.is the global leader dedicated to providing architects, engineers, constructors, and owner-operators with comprehensive architecture and engineering software solutions for sustaining infrastructure. Founded in 1984, Bentley has nearly 3,000 colleagues in more than 45 countries, $500 million in annual revenues, and, since 2001, has invested more than $1 billion in research, development, and acquisitions.
Код:
Rapidgator
https://rg.to/folder/7964518/OpenFlowsSewer2024Update224000221.html
Fileaxa
https://fileaxa.com/i3qja4pwbmjf/f9ce3.OpenFlows-Sewer-2024-Update-2-24-00-02-21.rar
TakeFile
https://takefile.link/ijnwrhhzsu4c/f9ce3.OpenFlows-Sewer-2024-Update-2-24-00-02-21.rar.html
Fikper Free Download
https://fikper.com/NEgJzSsrOU/f9ce3.OpenFlows-Sewer-2024-Update-2-24-00-02-21.rar.html
Links are Interchangeable - No Password - Single Extraction
